PTFE oil seal products have the following characteristics:
1、 It has excellent chemical stability and almost all chemical drugs have resistance. It can be used for sealing water, strong acids, strong bases, strong oxidizing agents, gas and other substances. However, due to differences in lip formula, in order to better meet usage requirements, please provide us with detailed usage requirements before production.
2、 It has excellent friction resistance, and the friction coefficient of PTFE lip is extremely low, only 0.02, which is 1/40 of rubber. It is particularly suitable for working in oil-free or low oil conditions, and can immediately have low friction characteristics even after long-term shutdown and reactivation.
3、 A single lip can withstand a pressure of 1.5 Mpa, while two lips can withstand a relatively high pressure of 3 Mpa. The rubber oil seal is only 0.03 Mpa; Specially suitable for high-speed rotating applications, with a line speed of up to 30m/s; Capable of working normally within the temperature range of -120 ℃ to 220 ℃.
4、 The PTFE oil seal lip is pulled into a trumpet shape during processing. Due to the memory shrinkage ability of PTFE after drawing, the frictional heat generated during operation causes the lip to continuously contract, so it does not require the help of a spring. It will tightly hold onto the shaft, preventing any gap from the shaft surface and compensating for wear.
Working temperature: -90 ° C to 260 ° C, instantaneous 300 ° C
Maximum speed: 25m/s line speed
Work pressure: Single lip vacuum to 1Mpa
Application environment: resistant to strong acids, strong alkalis, or strong oxidants, suitable for oil-free self-lubricating environments, and high cleanliness food and medical product processing environments.
A、 Vacuum, helium, hydrogen, Freon, nitrogen, argon, natural gas
B、 Mud water, sewage, cutting fluid, acidic and alkaline organic solvents
C、 Lubricating oil, hydraulic oil, gasoline, crude oil, sealant, aviation fuel
D、 Flour, putty powder, beverage, medical injection solution, oral medication powder
The specification table for stainless steel oil seals is as follows (please feel free to consult for detailed specifications):
ID | SIZE | ID | SIZE | ID | SIZE |
1 | 18*30*7 | 91 | 40*56*8 | 181 | 80*95*10 |
2 | 18*30*8 | 92 | 40*56*10 | 182 | 80*95*12 |
3 | 18*32*7 | 93 | 40*56*12 | 183 | 75*95.5*9.5 |
4 | 18*32*8 | 94 | 40*58*8 | 184 | 62*97*10 |
5 | 18*35*7 | 95 | 40*58*10 | 185 | 62*97*12 |
6 | 18*35*8 | 96 | 40*60*8 | 186 | 65*100*10 |
7 | 18*35*10 | 97 | 40*60*10 | 187 | 65*100*12 |
8 | 22*35*7 | 98 | 45*60*8 | 188 | 70*100*10 |
9 | 22*35*8 | 99 | 45*60*10 | 189 | 70*100*12 |
10 | 22*35*10 | 100 | 40*62*7 | 190 | 75*100*10 |
11 | 25*35*7 | 101 | 40*62*8 | 191 | 75*100*12 |
12 | 25*35*8 | 102 | 40*62*10 | 192 | 76*100*10 |
13 | 25*35*10 | 103 | 45*62*7 | 193 | 76*100*12 |
14 | 22*40*7 | 104 | 45*62*8 | 194 | 79*100*10 |
15 | 22*40*8 | 105 | 45*62*10 | 195 | 79*100*12 |
16 | 22*40*10 | 106 | 40*65*8 | 196 | 80*100*10 |
17 | 25*40*7 | 107 | 40*65*10 | 197 | 80*100*12 |
18 | 25*40*8 | 108 | 45*65*8 | 198 | 83*100*10 |
19 | 25*40*10 | 109 | 45*65*10 | 199 | 83*100*12 |
20 | 30*40*7 | 110 | 45*65*7 | 200 | 70*110*10 |
21 | 30*40*8 | 111 | 48*65*8 | 201 | 70*110*12 |
22 | 30*40*10 | 112 | 48*65*10 | 202 | 85*110*12 |
23 | 20*42*7 | 113 | 50*65*8 | 203 | 85*110*10 |
24 | 20*42*8 | 114 | 50*65*10 | 204 | 85*110*14 |
25 | 20*42*10 | 115 | 50*65*7 | 205 | 90*110*10 |
26 | 25*42*7 | 116 | 55*65*7 | 206 | 90*110*12 |
27 | 25*42*8 | 117 | 55*65*8 | 207 | 90*110*14 |
28 | 25*42*10 | 118 | 55*65*10 | 208 | 92*110*8 |
29 | 30*42*7 | 119 | 45*68*10 | 209 | 92*110*10 |
30 | 30*42*8 | 120 | 45*68*12 | 210 | 92*110*12 |
31 | 30*42*10 | 121 | 48*70*10 | 211 | 95*110*10 |
32 | 30*43*7 | 122 | 48*70*12 | 212 | 95*110*12 |
33 | 30*43*8 | 123 | 50*70*8 | 213 | 80*115*10 |
34 | 30*43*10 | 124 | 50*70*10 | 214 | 80*115*12 |
35 | 30*45*7 | 125 | 50*70*12 | 215 | 90*120*10 |
36 | 30*45*7 | 126 | 50*70*8 | 216 | 90*120*12 |
37 | 30*45*8 | 127 | 52*70*8 | 217 | 90*120*14 |
38 | 30*45*10 | 128 | 52*70*10 | 218 | 95*120*10 |
39 | 35*47*7 | 129 | 52*70*12 | 219 | 95*120*12 |
40 | 35*47*8 | 130 | 55*70*8 | 220 | 95*120*15 |
41 | 35*47*10 | 131 | 55*70*10 | 221 | 100*120*10 |
42 | 30*50*7 | 132 | 55*70*12 | 222 | 100*120*12 |
43 | 30*50*8 | 133 | 48*72*8 | 223 | 105*120*7 |
44 | 30*50*10 | 134 | 48*72*10 | 224 | 105*120*10 |
45 | 32*50*7 | 135 | 48*72*12 | 225 | 105*120*12 |
46 | 32*50*8 | 136 | 50*72*7.5 | 226 | 105*124*10 |
47 | 32*50*10 | 137 | 50*72*8 | 227 | 105*124*12 |
48 | 35*50*7 | 138 | 50*72*10 | 228 | 95*125*10 |
49 | 35*50*8 | 139 | 50*72*12 | 229 | 95*125*12 |
50 | 35*50*10 | 140 | 52*72*8 | 230 | 100*125*10 |
51 | 40*50*7 | 141 | 52*72*10 | 231 | 100*125*12 |
52 | 40*50*8 | 142 | 52*72*12 | 232 | 100*125*14 |
53 | 40*50*10 | 143 | 55*72*8 | 233 | 100*130*10 |
54 | 37*51*8 | 144 | 55*72*10 | 234 | 100*130*12 |
55 | 37*51*10 | 145 | 55*72*12 | 235 | 102*130*10 |
56 | 30*52*7 | 146 | 60*75*8 | 236 | 102*130*12 |
57 | 30*52*8 | 147 | 60*75*10 | 237 | 105*130*10 |
58 | 30*52*10 | 148 | 60*75*12 | 238 | 105*130*12 |
59 | 35*52*7 | 149 | 55*78*5 | 239 | 105*133.5*10 |
60 | 35*52*8 | 150 | 55*78*10 | 240 | 105*135.5*12 |
61 | 35*52*10 | 151 | 55*78*12 | 241 | 105*135*10 |
62 | 36*52*7 | 152 | 55*80*8 | 242 | 105*135*12 |
63 | 36*52*8 | 153 | 55*80*10 | 243 | 110*140*10 |
64 | 36*52*10 | 154 | 55*80*12 | 244 | 110*140*12 |
65 | 37*52*7 | 155 | 59*80*10 | 245 | 115*140*10 |
66 | 37*52*8 | 156 | 59*80*12 | 246 | 115*140*12 |
67 | 37*52*10 | 157 | 60*80*8 | 247 | 115*140*14 |
68 | 40*52*7 | 158 | 60*80*10 | 248 | 120*140*10 |
69 | 40*52*8 | 159 | 60*80*12 | 249 | 120*140*12 |
70 | 40*52*10 | 160 | 65*80*10 | 250 | 120*150*10 |
71 | 30*55*7 | 161 | 65*80*12 | 251 | 120*150*12 |
72 | 30*55*8 | 162 | 38*80*10 | 252 | 135*150*12 |
73 | 30*55*10 | 163 | 38*80*12 | 253 | 125*152.5*12 |
74 | 35*55*7 | 164 | 60*85*8 | 254 | 130*160*10 |
75 | 35*55*8 | 165 | 60*85*10 | 255 | 130*160*12 |
76 | 35*55*10 | 166 | 60*85*12 | 256 | 130*160*14 |
77 | 38*55*8 | 167 | 65*85*8 | 257 | 130*165*12 |
78 | 38*55*10 | 168 | 65*85*10 | 258 | 130*165*14 |
79 | 38*55*12 | 169 | 65*85*12 | 259 | 150*167*10 |
80 | 38*55*15 | 170 | 65*90*10 | 260 | 150*167*12 |
81 | 40*55*7 | 171 | 65*90*12 | 261 | 135*170*12 |
82 | 40*55*8 | 172 | 70*90*10 | 262 | 135*170*12 |
83 | 40*55*10 | 173 | 70*90*12 | 263 | 150*180*10 |
84 | 40*55*12 | 174 | 70*95*8 | 264 | 150*180*12 |
85 | 34*56*8 | 175 | 70*95*10 | 265 | 150*180*14 |
86 | 34*56*10 | 176 | 70*95*12 | 266 | 190*220*10 |
87 | 35*56*7 | 177 | 75*95*8 | 267 | 190*220*12 |
88 | 35*56*8 | 178 | 75*95*10 | 268 | 190*220*14 |
89 | 35*56*10 | 179 | 75*95*12 | 269 | 200*230*12 |
90 | 35*56*12 | 180 | 80*95*8 | 270 | 200*230*14 |
Applicable machinery: screw air compressor, vacuum pump, engine, gearbox, flour mixer, beverage slicer, stir fry machine, robot, medicine grinder, centrifuge, blower, explosion-proof motor, etc.
